Qingdao Liuyi Machinery Co., Ltd. food machinery manufacturer & vacuum frying machine
6 Years
| Ask Lasest Price | |
| Brand Name : | Liuyi |
| Model Number : | VF-LY50, VF-LY-100, VF-LY-200 |
| Price : | Price Can Be Negotiated |
| Payment Terms : | T/T |
| Supply Ability : | 50 Sets per Month |
| Delivery Time : | 20~25 Days After Receiving The Deposit |
Fruit Chips Making Machine 200kg/ Batch For Green Radish
Green radish is rich in nutrients. The amylase content is high. It contains less calories, more cellulose, and it is easy to produce a feeling of fullness after eating, which contribute to weight loss. Radish can induce the body to produce interferon itself to increase the body's immunity, and inhibit the growth of cancer cells. These are all play an important role in preventing cancer.
VF Green radish chips are increasing popular recently. It selected fresh green radish raw materials, processed by low temperature freezing and refined palm oil as dehydration medium. It belongs to vacuum low temperature (80 degrees -95 degrees) dehydration, different from puffing, hot air drying and deep-fried foods. The green radish chips treated by vacuum low-temperature dehydration retain 95% of the nutrients and natural flavor of fresh green radish, crispy and delicious. We will introduce our VF machine advantages in the following details.
1. The machine only needs a short frying time and the oil temperature is stable. The temperature difference of the oil during the frying process can be controlled at 1 °C.
2. One-time feeding is 200kg. Fully automatic computer control, one person can operate several sets at the same time.
3. Uniquely designed vacuum pump with good vacuum retention and low noise (below 60dB).
4. The heating speed is fast, the required temperature can be reached after 8-13 minutes from starting. The oil circulation is large.
5. Special oil inlet design, evenly fried to make perfect color of finished product.
| Model | LY-200 |
| Dimension | Outside 2500*3100*4500 |
| Weight | 2760kg |
| Vacuum Pump Power | 15kw |
| Oil Pump Power | 7.5kw |
| Steam Pressure | 0.4~0.8mpa (adjustable) |
| Vacuum Degree | -0.095mpa~-0.098mpa |
| Working Temperature | 75-110℃ (adjustable) |
| Control System | Full Microcomputer automatic control |
| De-oil Speed & Form | 300 r/min Inside-collocate de-oil |
| Working Capacity | 170~200kg |
| Basket size | Φ1200mm*H600mm |
Qingdao Liuyi Machinery Co., Ltd can provide you with one-stop customized service. With more than 20 years of experience in food processing, we can customize the machine according to your plant, product requirements and other special needs.
Welcome to visit the factory and look forward to working with you as soon as possible.
| Model | Basket size (mm) | Capacity (kg/batch) | Power (kw) | Overall size (mm) |
| VF-LY50 | dia600*500 | 30~50 | 15 | 1400*3500*2500 |
| VF-LY100 | dia750*530 | 80~100 | 22 | 1800*4000*2900 |
| VF-LY200 | dia1200*600 | 150~200 | 30 | 2500*4500*3100 |
- Oil storage tank
It is for oil storage before frying. The oil will be heated in it firstly. During frying, the oil will be cycled between oil storage tank and frying pot.
- PLC control system
Brand: Mitsubishi
It is control the whole machine.
This make the machine operate fully automatically. No need to manual during processing.
- Touch screen
Brand: Mitsubishi
The new type is connect directly with the machine body, not separate part.
It is easy to understand and operate.
- Electrical Components
Brand: Schneider
It mainly includes dis-connector, frequency converter and thermal overload relay.
1. The color is attractive, fresh and taste is crisp.
2. Attracting aroma
3. Casual and fashion, long aftertaste
Catalog for Automatic Vacuum Frying Machine.pdf
In recent years, our company's technological innovation has continued to develop. The number of invention patents has continuously increased. Companies in good faith, quality, innovation, professionalism, unity, and enterprising, to achieve manufacturing, installation, one-stop after-sales service. We can better serve our customers. Excellent professional technical and sales talents, as well as advanced technology and engineering level, will solve the challenges you face in the production.
Our company will sincerely cooperate with friends from all walks of life to develop together.
1. Fumigation wooden case with water-proof embrace
2. Nude pack after plastic film wrapping
3. Upon your requirements
We provide high quality service:
1) Consultation before, during, and after sales;
2) Project planning and design;
3) Debugging until everything is functional;
4) Shipping management from factory to the destination;
5) Installing, maintenance and operation training;
6) New production techniques and formulas;
7) 1 year complete warranty and life-time maintenance service.
FAQ
1) When can I get the price?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
2) How do you make your price?
We make the price according to our comprehensive costing. And our price will lower than the trade company because we are manufacturer. You will get competitive price and high quality.
3) Can you guarantee your quality?
Of course. We are the factory. More important, we put a high value on our reputation. High quality is our principle all the time. You can be assured on our production completely.
4) How long does the whole procedure being worked out?
After you place an order, for small quantity 15-20 days is enough. For big quantity, we can talk further.
5) What about the transportation and delivery date?
Normally we use sea for shipment to save customer's money. It is about 25-40 days. It also depends on which country and port you are. If there are some emergencies we can send the goods by air, or by international express, as long as you afford the traffic expense.
|
|
