    Vacuum Star Fruit Chips Making Machine With Steam / Electric Heating Source

    Ask Lasest Price
    Brand Name : Liuyi
    Model Number : VF-LY50, VF-LY-100, VF-LY-200
    Price : Price Can Be Negotiated
    Payment Terms : T/T
    Supply Ability : 50 Sets per Month
    Delivery Time : 20~25 Days After Receiving The Deposit
    • Product Details
    • Company Profile

    Vacuum Star Fruit Chips Making Machine With Steam / Electric Heating Source

    Vacuum Fryer Fruit Chips Making Machine With Steam / Electric Heating Source


    • Features of star fruit chips fried vacuum fryer produced by Liuyi

    1. De-oiling speed is high. It can reach 300rmp/min, the oil content is low.

    2. The de-oiling frequency can be controled and adjusted. It fits for all the goods with low and high oil content. Low speed use for frying, high speed for de-oiling. Time relay control the forward or reverse of basket to strengthen the heat transfer effect.

    3. The heater is made of 304 stainless steel, which is resistant to high temperature and fluoroolefin. It is easy to clean with water and protects the product from secondary pollution.

    4. The oil heating speed is high and area is large. The oil circulation is about 35-40m3/min. It only need 8-13mins to reach needed temperature. The heating is evenly to make sure the color is good.

    5. Vacuum pump noise is below 60db.


    • Star fruit chips fried vacuum fryer machine Technical Data
    ModelBasket size (mm)Capacity (kg/batch)Power (kw)Overall size (mm)
    VF-LY50dia600*50030~50151400*3500*2500
    VF-LY100dia750*53080~100221800*4000*2900
    VF-LY200dia1200*600150~200302500*4500*3100

    Qingdao Liuyi Machinery Co., Ltd. adheres to the management philosophy of “Quality First, Customer First” and inspires to provide customers with comprehensive and meticulous services. From product quality and performance to after-sales service and training, customers can feel the quality and thoughtful service from Liuyi Machinery. Welcome your consultation.


    • Vacuum Frying Machine Core Components Produced by Our Company

    - Oil storage tank

    It is for oil storage before frying. The oil will be heated in it firstly. During frying, the oil will be cycled between oil storage tank and frying pot.


    - PLC control system

    Brand: Mitsubishi

    It is control the whole machine.

    This make the machine operate fully automatically. No need to manual during processing.


    - Touch screen

    Brand: Mitsubishi

    The new type is connect directly with the machine body, not separate part.

    It is easy to understand and operate.


    - Electrical Components

    Brand: Schneider

    It mainly includes dis-connector, frequency converter and thermal overload relay.


    Catalog for Automatic Vacuum Frying Machine.pdf
