Continuous Vacuum Frying Machine Oil Filter Integrated Design Electric Saving

Continuous Vacuum Fryer Feature

1. Stable oil temperature
It eliminates the differential temperature frying happen in intermittent fryer, in which the oil quality deterioration will happen because of high temperature. It has the more uniform frying and makes the chip more puffing. So the product quality is obviously improved;
2. Continuous de-oiling, adjustable speed
The continuous fryer solves the problem that the oil content of the inner and outer layers of the basket is uneven, which will happen in the intermittent fryer. It can ensure that the product is evenly de-oiled, and control the oil content to a minimum.
3. Continuously oil filtration, automatic oil replenishment and cleaning impurity.
Fully automatic computer control is a breakthrough design in the vacuum frying field.
4. Save human resource
The process parameters are controlled by computer, which eliminates the factors that affect the quality of the product artificially.
5. Saving coal and electricity
It uses small batch continuous feeding operation. The power and fuel consumption are significantly lower than intermittent operation, saving about 30% of electricity, saving about 40% of coal;
6. Stable vacuum condition
The optimized design of the new vacuum pump stabilized the vacuum at 0.098 Mpa, which can make the product the best shape and color. At the same time, it can adapt to the different climates.

Advantages

1. Low noise
Low noise because we applied a small invention for the vacuum pump on our machine, it is atmospheric ejector, which make the noise is below 60db.

2. Electric saving
Since our structure is simple, not need that much electrical parts, the total power for 200kg input is 30kw.

3. Oil filter integrated design
We have vacuum oil filter tank to match with our automatic snacks vacuum frying equipment. The whole process is also automatic. There is an vacuum pump on the filter tank, it can pump the oil from storage tank into the filter tank.

We all know after several batches, there will be bad smell and also dirty scrap(sugar) in the oil. In order to keep good quality of final chips, the oil need to be filtered.

Machine Technical Data

• Vacuum Frying Machine Core Components

- Oil storage tank
It is for oil storage before frying. The oil will be heated in it firstly. During frying, the oil will be cycled between oil storage tank and frying pot.

- PLC control system
Brand: Mitsubishi
It is control the whole machine.
This make the machine operate fully automatically. No need to manual during processing.

- Touch screen
Brand: Mitsubishi
The new type is connect directly with the machine body, not separate part.
It is easy to understand and operate.

- Electrical Components
Brand: Schneider
It mainly includes dis-connector, frequency converter and thermal overload relay.

Catalog for Automatic Vacuum Frying Machine.pdf

• Our Certification

In recent years, our company's technological innovation has continued to develop. The number of invention patents has continuously increased. Companies in good faith, quality, innovation, professionalism, unity, and enterprising, to achieve manufacturing, installation, one-stop after-sales service. We can better serve our customers. Excellent professional technical and sales talents, as well as advanced technology and engineering level, will solve the challenges you face in the production.
Our company will sincerely cooperate with friends from all walks of life to develop together.

• Packing & Delivery

1) All machines which need packaged will be covered by film then put into the export standard wooden pallet, use the cystosepiment to prevent breaking on ship.
2) The wooden cases will be fixed inside the container tightly by the rope.
3) Export standard wooden pallet will be used for easy unloading for customers.

• After-sale service

We provide high quality service:
1) Consultation before, during, and after sales;
2) Project planning and design;
3) Debugging until everything is functional;
4) Shipping management from factory to the destination;
5) Installing, maintenance and operation training;
6) New production techniques and formulas;
7) 1 year complete warranty and life-time maintenance service.
